2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate 1.5mm-150mm Thickness for Aircraft Structural Components

  • 2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate 1.5mm-150mm Thickness for Aircraft Structural Components
  • 2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate 1.5mm-150mm Thickness for Aircraft Structural Components
Lugar de origen Shandong, China
Nombre de la marca Hongtu
Certificación ISO 9001:2015, SGS, AMS-QQ-A-250/4
Número de modelo 2024-T3
Cantidad de orden mínima 500 kilos
Precio USD 3.5-5.8 / kg
Detalles de empaquetado Papel antioxidante intercalado, plataforma de madera de calidad de exportación con flejes de acero,
Tiempo de entrega 5-7 días laborables para stock, 15-25 días para producción
Condiciones de pago T/T,LC,PayPal,Western Union
Capacidad de la fuente 2000 toneladas por mes
Datos del producto
Aleación 2024 Temperamento T3, T351, T4
Espesor 1,5 mm - 150 mm Ancho 1000 mm, 1250 mm, 1500 mm, 2000 mm, 2500 mm
Longitud 2000 mm, 2440 mm, 3000 mm, 6000 mm o personalizado Estándar ASTM B209, AMS 4035, AMS 4037, EN 573
Acabado superficial Acabado laminado, anodizado, revestido, pulido. Resistencia a la tracción ≥ 485 MPa
Fuerza de producción ≥ 345MPa Alargamiento ≥ el 12%
Solicitud Estructuras De Aeronaves, Fuselaje, Largueros De Ala, Equipo
Resaltar

2024 T3 Aerospace Aluminum Sheet

,

Aircraft Grade Alloy Plate 2024

,

High Strength Aviation Aluminum Plate
Deja un mensaje
Descripción de producto
2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate 1.5mm-150mm Thickness for Aircraft Structural Components
2024 T3 Aerospace Grade Aluminum Alloy Sheet Plate

The 2024 T3 aluminum alloy sheet is a high-strength, heat-treatable alloy renowned for its excellent strength-to-weight ratio and superior fatigue resistance. Widely used in aerospace and aviation industries, this alloy delivers reliable performance in demanding structural applications.

Key Features
  • High Strength: Tensile strength ≥ 485 MPa in T3 temper, rivaling mild steel strength with 1/3 the weight
  • Excellent Fatigue Resistance: Engineered to withstand repeated stress cycles in aircraft applications
  • Good Machinability: Superior cutting and forming characteristics for complex component manufacturing
  • Heat Treatable: Solution heat-treated and cold-worked for enhanced mechanical properties
  • Natural Aging: Stable mechanical properties achieved through natural aging process
Chemical Composition (Weight %)
Element Si Fe Cu Mn Mg Cr Zn Ti Al
Min - - 3.8 0.3 1.2 - - - Remainder
Max 0.50 0.50 4.9 0.9 1.8 0.10 0.25 0.15
Mechanical Properties (T3 Temper)
Property Value
Tensile Strength ≥ 485 MPa
Yield Strength ≥ 345 MPa
Elongation ≥ 12%
Hardness (Brinell) 120 HB
Density 2.78 g/cm³
Available Dimensions
Parameter Range
Thickness 1.5mm - 150mm
Width 1000mm - 2500mm
Length 2000mm - 6000mm or Custom
Temper T3, T351, T4, T42
Applications
  • Aircraft fuselage skins and structural panels
  • Wing spars, ribs and stringers
  • Vehicle armor plates
  • High-performance truck wheels
  • Precision machined components and fittings
Our Advantages
  • Strict Quality Control: Every batch undergoes spectrographic analysis, tensile testing and ultrasonic inspection
  • Complete Traceability: Mill test certificates (MTC EN 10204 3.1) provided with every shipment
  • Flexible MOQ: Small trial orders accepted from 500 kg
  • Professional Packaging: Export-grade wooden pallets with anti-corrosion paper and PE film wrapping
  • Fast Delivery: Extensive stock inventory for prompt shipment; custom production within 15-25 days
Contact us today for a competitive quotation, free sample cutting, and technical consultation on 2024 T3 aerospace aluminum sheets.
